Gazco Reflex 105 Balanced Flue Gas Fire with Icon XS Black Glass Frame

Gazco Reflex 105 Balanced Flue Gas Fire with Icon XS Black Glass Frame

• Icon XS Black Glass Frame
• Glass Fronted Log Flame Effect
• Up to 92% Gas Fire Efficiency
• 12kW Gas Heat Input
• Up to 9.9kW Gas Heat Output
• Flue Type: Balanced Flue Gas

• Remote Control as standard

Gazco Reflex 105 Balanced Flue Gas Fire with Icon XS Black Glass Frame

Surrounded only by your interior décor, the Reflex 105 Edge gas fire provides the ultimate in contemporary fireside ambiance, with nothing but the expansive flame picture on show.

All Reflex fires come with a Programmable Thermostatic Control, the Gazco Harmony¹⁰. Gazco’s Harmony10 control system gives you complete control over the Reflex 105’s features. Ignite and adjust the front and rear flames, along with the brightness of the ambient EmberLight LED fuel bed. Program the fire either thermostatically or with daily scheduling to suit your lifestyle.

Dancing flames. A glowing ember bed. Logs that look as real as, well… the real thing. These are all the elements that make the landscape Reflex 105 so realistic, you may find it hard to believe it’s a gas fire. And with its wealth of styling options, the 105 gives you the freedom to tailor your fire to your home. So whatever your tastes — you will experience the extraordinary.

Gazco Reflex 105 Specification:
Safety Flame Supervision Device (FSD)
Airwatch System
Type of Heat: Radiant & Convection
Heating Efficiency: 92%
Heat Input High: 12 kW
Heat Output High: 9.9 kW

Fuel Bed Options:
Log Effect with LED fuel bed for added realism

Firebox Lining Options:
Brick effect, Ledgestone Effect, Black Glass, or Black Reeded

Control Options:
Brand New Harmony10 Remote Control - Sequential & Programmable

Installation requirements:
Air Vent not required
Balanced Flue Kit required

There are 2 Balance Flue kits available, these are as follows:

Balance Flue Option 1: Up & Out (Vertical Exit 90 Degree Bend)
Kit Number: 8567
Colour: Stainless Steel
Components (1 X 940mm Straight, 1 X 462mm terminal length & 1 X 90 Degree Bend)
(NB Guard Required for below 2m)


Balance Flue Option 2: Off The Top (Vertical Flue)
Kit Number: 8524
Colour: Stainless Steel
Components (2 X 1000mm Straight & 1 X 1000mm terminal length)

Technical Diagram:

As a PASSIVE HOUSE GAS FIREPLACE-PASSIVE HOME FIREPLACE-this appliance will result in a higher BER rating in your Irish home.
